/Low Voltage Drive

Good Drive200A (GD200A) – General Purpose Drive

Basic details :

General Purpose Drive
Voltage Range:
  • AC 3PH 380V(-15%)–440V(+10%)
    – 0.75 to 500Kw
8 Digital Input / 1 Digital Output
1 High Speed DI / 1 Open Collector DO
1 Analog Input / 2 Analog Output
2 Relay Output
400Hz Max Freq Output

Application -

Air Compressor
Oil Industry
Mines
Fan and Water Pump
Plastic Machinery

Features -

More Accurate Motor Autotuning
Advanced open loop vector control
Up to 0.5Hz/150% starting torque
Built-in braking unit (≤30kW), Optional external braking unit (≥37kW)
Standard C3 filters; Optional C2 filters
Support G/P dual rating
